KELLYS Theos F70 SH M 29"/27.5" 820Wh 2025 (168-183cm)

rám KELLYS THEOS F70 Carbon-Aramid Composite / Designed & manufactured in EUROPE / Think Link® suspension system, 170 mm rear travel, integrated removable battery, 1.8" tapered HT, post mount 203 mm, mullet 29/27.5"+ wheelset, 12x148 mm Boost thru axle
vidlica ROCK SHOX Zeb Select+ (29) Boost, 180 mm, DebonAir+ / Charger 3 RC2 / Maxle Stealth 15 mm thru axle
zadný tlmič ROCK SHOX Super Deluxe Select+ RT, DebonAir+ / Open-Threshold (230x65 mm)
veľkosť rámu M / L
Pohon motor SHIMANO EP801, 85 Nm, 36 V
batéria KELLYS Re-Charge K1 Li-ion internal removable 820 Wh / capacity 23 Ah, co-developed by Kellys-BMZ
radiaca jednotka SHIMANO SW-EN800-L for assist
cyklopočítač Shimano SC-EN500 cycle computer with assist switch
kľuky SHIMANO EM600 / CRE70-B (34T) - dĺžka 170 mm
menič SHIMANO Deore XT Linkglide M8130 (direct mount)
radenie SHIMANO Deore XT Linkglide SL-M8130-R Rapidfire Plus (I-Spec EV)
počet prevodov 11
kazetový pastorok SHIMANO Linkglide CS-LG600-11 (11-50T)
reťaz SHIMANO Linkglide CN-LG500
brzdy SHIMANO Deore XT M8120 Hydraulic Disc
brzdové páky SHIMANO Deore XT BL-M8100
brzdové kotúče predný SHIMANO RT64 220 mm / zadný EM300 203 mm
kolesá predné NOVATEC M30 622x30 / zadné NOVATEC M35 584x35 Center Lock (15x110 mm / 12x148 mm)
plášte predný SCHWALBE Eddy Current Evo Super Trail 62-622 (29x2.40) Tubeless Easy, ADDIX Soft, folding / zadný SCHWALBE Eddy Current Evo Super Gravity 65-584 (27.5x2.60) Tubeless Easy, ADDIX Soft, folding
pevná os predná ROCK SHOX Maxle Stealth 15x110 mm / zadná Mr.control 12x177 mm
hlavové zloženie ACROS 1.8 tapered semi-integrated
predstavec RACE FACE Aeffect R 35 - diam 28.6 mm / bar bore 35 mm / 0° / dĺžka 50 mm
riadidlá RACE FACE Chester 35 RiseBar - diam 35 mm / rise 35 mm / šírka 780 mm
rukoväte KLS Poison
sedlovka KS Rage-i Remote Telescopic - diam 30.9 mm / dĺžka 442 mm, zdvih 150 mm (M) / dĺžka 495 mm, zdvih 170 mm (L)
sedlo fi’zi:k Taiga, S-alloy rails
